Screen International has introduced a Pop-Up Table Lift. The TL-15 is a unique and complete accessory that enables the installer to hide a projector inside a table or a piece of furniture and silently lift it for use.
The Pop-up Table Lift TL-15 is a unique and complete accessory that enables the installer to hide the projector inside a table or a piece of furniture. In developing this product, the R&D Department has focussed its efforts on three different but strategic issues:
• Maximum safety for the user
• Ease and flexibility of installation
• Smart exclusive Italian design
The POP-UP TABLE LIFT TL-15 is therefore very suitable for both Home Cinema applications and A/V Professional environments. This silent operating elevator can pop up video-projectors up to 25 kg’s. The maximum raised height of the pop-up lift is 140 mm, which can be adjusted by the installer at the desired height.
In order to guarantee the maximum stability, the lift is equipped with two motors.
The inside of the lift has a smart cable management system in place. In order to offer a high quality finishing of the product, the housing is made of brushed stainless steel and on top of the table lift is a semi-transparent satin Plexiglas cover.
TECHNICAL DATA:
Net dimensions of the base support for projector: 330×470 (Width x Depth in mm.)
Maximum load allowed: 25 kg
Maximum raised height: 140 mm
Net weight of the elevator: 21 kg
MOTOR SPECS:
Maximum consumption: 130 W each engine
Raise up speed: 25 mm/sec
Power supply: 220-230 V – 50 Hz
